SOLOBOIS® S44 (N2-W7-A)
Reference: S44
Timber clad crash barrier CE marked
- Description
- Technical data
- Product view
- Downloads
Description
Guaranteed for 10 years, the SOLOBOIS® crash barrier is a must wherever road safety and integration into the environment are a priority.
SOLOBOIS® S4.4 is a product developed and manufactured by SOLOSAR.
The split has been increased to facilitate the installation on site.
Its 4-meter long beam incorporates a flat steel wrapped in a log made of pinus sylvestri class 4 EN335 treated.
Technical data
SPECIFICATIONS:
SOLOBOIS® S4.4 has been crash tested according EN 1317 in level: N2 - W7 - ASI A and marked CE under n° 1826-CPR-12-02-18-DR02 du 27 mars 2020.
The steel is completely invisible from the front and rear of the crash barrier and the steel post is hidden by wood cladding.
S4.4 is available in galvanized or powder-coated steel.
Post: C100 to be rammed into the ground
Height: 1,50m
Available in 4m post spacing: SOLOBOIS® S.4.2
Full truck load capacity: 800 lm of timber clad crash barrier SOLOBOIS® S4.4
Product view
 |
SOLOBOIS® S4.4 - Side view |
 |
SOLOBOIS® S4.4 - Components assembly |
 |
SOLOBOIS® S4.4 - Assembly process |
Downloads
- SOLOBOIS S44 product sheet
- CE mark ( accès réservé)
To give you an overview of our range of SOLOWOOD® steel backed timber guardrail solutions, you can now download the full brochure with all the product sheets and technical details you need to make the right choice below.
 |
TDownload our full WOOD® catalogue (PDF - 28 MB) by clicking on the image opposite |
