SUPER-RAIL ECO H2-W4
- Description
- Technical data
- Product view
Description
Super-Rail Eco is a H2 road restraint system combining high containment level and light weight.
The Super-Rail Eco consists of a top beam to prevent heavy vehicles from tipping over and a bottom beam dedicated to light vehicles.
Technical data
SPECIFICATIONS:
Tested length: 52m in H2 level.
CE mark N°: 0008 - CPR - 2011
Available connections: Super-rail Eco BW (H2-W4-A) and HBB 1.33 Plus-HLK (L1-W3-A)
Post: C125 in S235 JR steel;
Length: 1,90 m
Beam profile: AD profile in S235 JR steel
Weight per lm: 38,5 kg
Post spacing: 2.0 m
Product view
